1.Built in rechargeable Li-ion battery
2.RGB side warning lights and center strong white working lights.
3.Multiple lighting modes satisfy differrent lighting applications.
4High protection grade, shatter-proof, crush-proof, water-proof, anti-explosive.
5.High vision, 300meters during the day, 1000meters in evening, 1600meters in water..
6.Small size and light weight for easy carrying.
7.Magnetic adsorption.
8.Charging box is available.
Specification
| GL-WF03 | Side warn lighting | Center work lighting |
| Light source | 16 leds f5 RGB | 1 main light + 12 auxiliary lights |
| Light current | 7mA*16 leds=112mA | 200mA - 400mA - 60mA-120mA |
| Light modes | Ten indication modes: Rotate - Double blink - Single blink - Alternate - SOS - Solid on (low) - Solid on (high) - Red/blue alternate - Red/green alternate - Blue/green alternate |
Four work lighting modes: Main light WeakMain light StrongAuxiliary lights cold whiteAuxiliary lights warm white |
| Wave length | R: 630 / G: 525 / B:465 |
|
| Luminous intensity | R: 1500cd / G: 8000cd / B: 4000cd | 100 Lm - 195 Lm - 35 Lm - 60 Lm |
| Brightness |
| 2500 Lux - 6000 Lux - 1500 Lux - 2200 Lux |
| Light power | 0.08W | 0.74W - 1.5W - 0.25W- 0.45W |
| Working time | 80~100H | 15H - 7H - 55H - 25H |
| Materials | PC + silicone |
| Storage temperature | -20~+80 ℃ |
| Rated voltage | 3.7V |
| Battery capacity | 3400mAh rechargeable Li-Ion battery |
| Battery cycles | 1200 Cycles |
| Dimension | 105mm(Diameter) * 39mm(Height) |
| Weight | 241g |
| Charging current | 1.5A |
| Charging time | 3H |
| Waterproof grade | IP68 |
Company introduction
Green Lighting Technology Co., LTD (GLT) is an original manufacturer specializing in LED mining lights, explosion-proof flashlights, underground mining LED strip lights, charging racks, Miner belts, and portable emergency power stations. Our company is located in Shenzhen, and we have a professional R&D team to support customers' special customized requirements, providing complete after-service. Our products have been sold to around 60 countries, and we have obtained patents and certifications on the invention of several products.
Our Service
1.We also can provide OEM,OED special mining lamps according to your detail requirement(LOGO,color,appearance,function, structure etc)
2. High quality and competitive price .
3.Can according to your requested to design new item that suitable for your market.
4.Our company's product has one year warranty.
Accept Customized as client's requirements:
Appearance
Strong ID Team, According to client's market positioning, use condition to design product shape, pattern and colour.
Recently,customized the semi-corded, corded, cordless with Tracking position and Infrared receiver
Electronic Circuit
Rich Experience Software and Hardware Engineers, PCB's Design and Layout. LED Driver, Charging circuit, Battery Protection Circuit and so on.Write the request to cap lamps, such as clients company name, LOGO, serie No and user name.
Structural Design
Professional MD Team, provide IP68 Waterproof, ATEX explosion-proof, Dust-proof Products, 17 years work experience in underground field. Very familiar with miner's lamp industry products. MD team will field visit and according the use condition to design thewaterproof.
Optical Design
According to LED Luminous Flux, Light cup curve and current to design the Light Beam
Packing&Delivery
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What is the lead time?
A: Sample needs 7-10days, mass production time needs 25-30days.
Q3. Do you have any MOQ limit?
A: Our MOQ EXW is 1 pc for sample; MOQ FOB is 200pcs.(Depends on different type battery/battery pack)
Q4. How do you ship the goods and how long does it take arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 5-7 days to arrive.
Q5. How to proceed the order when customer order products?
A: Inquiry-Confirmation-Send Proforma Invoice-Customer make payment-Arrange production-ship the
goods to customers-Confirmation-Finish.
Q6. How to make this payment?
A: TT, Paypal, Western Union.
Q7. Do you offer guarantee for the products?
A: Yes, we offer one year guarantee for the products.
Q8. Do you accept OEM/ODM?
A: Yes, it’s available.
